The EveryDrop Filter 3 (EDR3RXD1) is a genuine Whirlpool refrigerator water filter that replaces the older W10193691. It fits select KitchenAid, Whirlpool, Maytag, Amana, and Kenmore side-by-side and top freezer refrigerators with a base grille filter housing at the bottom front of the fridge.

NSF certified to reduce 24 contaminants including lead, chlorine, cysts, and pharmaceuticals. Replace every 6 months or 200 gallons.

Searching for the right filter and not sure if the EDR3RXD1 is what your fridge takes? You are not alone. Filter 3 is one of the most searched but also most confused filters because it looks similar to other EveryDrop filters but sits in a completely different location. This guide clears that up fast, tells you exactly what it fits, what it removes, and how to swap it out in under 3 minutes.

Is the EDR3RXD1 the Right Filter for Your Fridge?

The EDR3RXD1 is your filter if the label inside your fridge says Filter 3 or W10193691, or if you have a KitchenAid, Whirlpool, Maytag, or Kenmore side-by-side refrigerator with a filter slot in the base grille at the bottom front.

Still not sure? Use this quick check:

Check This	If Yes — You Need EDR3RXD1
Filter label says Filter 3 or W10193691	Yes — EDR3RXD1 is the direct replacement
Filter housing is in the base grille (bottom front of fridge)	Yes — this is the grille-mount filter slot
Fridge brand is KitchenAid, Whirlpool, Maytag, or Kenmore	Likely yes — confirm with your filter label
You have a side-by-side or top freezer refrigerator	High chance — most side-by-side models use Filter 3

Pull out the filter currently installed and check the label. If it says Filter 3, W10193691, or EDR3RXD1 this is your replacement.

What Is the EveryDrop Water Filter 3?

The everydrop water filter 3  part number EDR3RXD1  is the OEM refrigerator water filter made by Whirlpool Corporation under the EveryDrop brand. It replaced the older W10193691 and upgraded certified contaminant reduction from 7 to 24 contaminants.

What makes Filter 3 unique compared to Filter 1 and Filter 2 is its location. It mounts in the base grille at the bottom front of the refrigerator rather than inside the fridge. This is important because it means the replacement process is slightly different.

Like all EveryDrop filters, it uses activated carbon block technology  forcing water through compressed carbon that traps contaminants through adsorption without removing beneficial minerals.

What does the EDR3RXD1 filter out?

The edr3rxd1 water filter is NSF 42, 53, and 401 certified to reduce 24 contaminants:

Category	Contaminants Reduced
Heavy metals	Lead, mercury, asbestos
Chlorine	Taste and odor
Cysts & parasites	Cryptosporidium, Giardia
Pharmaceuticals	Atenolol, carbamazepine, and others
Emerging contaminants	BPA, estrone, MTBE
Sediment	Turbidity, cloudiness

Generic filters are typically only NSF 42 certified.They reduce chlorine taste and odor but not lead, cysts, or pharmaceuticals. The genuine EDR3RXD1 covers all three.

Which Refrigerators Are Compatible With the EDR3RXD1?

The edr3rxd1 is not a universal filter. It fits side-by-side and top freezer refrigerators with a base grille filter housing. Here are the main compatible brands and model examples:

Brand	Compatible Model Examples	Filter Location
KitchenAid	KSRG25FVBL, KSRS25RVMS, KSRG25FVWH	Base grille (bottom front)
Whirlpool	WRS325FDAM, WRS321SDHZ, WRS555SIHZ	Base grille (bottom front)
Maytag	MSS25C4MGZ, MSF25D4MDM	Base grille (bottom front)
Kenmore	51762, 51769, 51773	Base grille (bottom front)
Amana	ASD2575BRS, ASD2522WRD	Base grille (bottom front)

Cross-reference part numbers

If your current filter has any of these part numbers, the EDR3RXD1 is your direct replacement:

Part Number	Notes
EDR3RXD1	Current EveryDrop OEM part number
W10193691	Older Whirlpool part number — same filter
EDR3RXD1B	Minor revision — fits same fridges, same performance
W10193691A	Alternate older part number
9083	Kenmore equivalent part number

KitchenAid Fridge Water Filter | Why Does It Use EDR3RXD1 ?

Most KitchenAid fridge water filter searches for side-by-side models lead to the EDR3RXD1. KitchenAid side-by-side refrigerators almost universally use a base grille mounted Filter 3 housing  which is exactly what the EDR3RXD1 fits.

If you own a KitchenAid side-by-side fridge and are confused between Filter 2 and Filter 3. The easiest way to tell is where the filter sits. Interior upper housing = Filter 2. Base grille = Filter 3.

KitchenAid fridge filter tip: Look at the bottom front of your KitchenAid fridge. If you see a small rectangular grille with a push-button or twist slot , that is your Filter 3 housing. The EDR3RXD1 is what goes in there.

EDR3RXD1 vs EDR2RXD1,  What Is the Difference?

Both filters are common for KitchenAid and Whirlpool fridges  which causes a lot of confusion. Here is the key difference at a glance:

Feature	EDR3RXD1 (Filter 3)	EDR2RXD1 (Filter 2)
Primary fridge type	Side-by-side, top freezer	French door, bottom freezer
Filter location	Base grille (bottom front)	Interior upper housing
Main brands	KitchenAid, Whirlpool, Kenmore	KitchenAid, Whirlpool, Maytag
Replaces	W10193691	W10413645A
NSF certified contaminants	24	24
Interchangeable?	No	No

Important: EDR3RXD1 and EDR2RXD1 are not interchangeable. The biggest giveaway is filter location,  if your filter is in the base grille at the bottom, you need EDR3RXD1. If it is inside the fridge in the upper area, you need EDR2RXD1.

How to Replace the EveryDrop Filter 3 Step by Step

Replacing the everydrop filter 3 is slightly different from other filters because it is in the base grille, not inside the fridge. Still takes under 3 minutes with no tools.

Step 1 — Locate the filter: Find the base grille at the very bottom front of your refrigerator. The filter slot is usually on the left side of the grille.

Step 2 — Open the grille or press eject: Some models have a push-button eject — press it and the filter pops out. Others require you to twist the filter a quarter turn counterclockwise first.

Step 3 — Remove the old filter: Pull the filter straight out toward you. Have a cloth or paper towel ready — a small amount of water may drip.

Step 4 — Insert the new EDR3RXD1: Remove the cap, align the filter, push in firmly and twist clockwise until it locks. You will feel a click when it is seated correctly.

Step 5 — Reset the filter indicator: Hold the filter reset button on your control panel for 3 seconds until the light turns green or blue.

Step 6 — Flush the system: Run 2-3 gallons of water through the dispenser and discard before drinking.

Base grille filters drip more than interior filters when removed.Always have a cloth ready before pulling the old one out.

How Often Should You Replace the EDR3RXD1?

Replace the edr3rxd1 water filter replacement every 6 months or 200 gallons , whichever comes first.

Signs your filter needs replacing now

Do not wait for the indicator to turn red. Replace sooner if you notice:

✓    Water from the dispenser tastes or smells off

✓    Water flow is noticeably slower than usual

✓    Ice has an unusual taste or odor

✓    Filter indicator light is orange or red

✓    More than 5 months have passed with heavy household usage

Lifespan by household size

Average replacement schedule based on daily dispenser use:

•      1-2 people — full 6 months comfortably

•      3-4 people — replace at 4-5 months

•      5+ people or heavy ice usage — replace every 3-4 months

An overdue filter does not just stop performing — it can start pushing trapped contaminants back into your water. Replace on schedule.

How Much Does the EveryDrop Filter 3 EDR3RXD1 Cost?

Here is a clear breakdown of your options:

Option	Price Range	Best For
Genuine EveryDrop EDR3RXD1	$45 – $55	Full 24-contaminant protection + warranty
NSF-certified generic (e.g. Waterdrop)	$15 – $30	Budget buyers — basic chlorine reduction
3-pack OEM	$90 – $120	Best value — 18 months of coverage

A 3-pack is the smartest buy if you plan to stay in your home. Works out cheaper per filter and keeps you stocked for 18 months without having to reorder.

Genuine EveryDrop EDR3RXD1 vs Generic Alternatives

Third-party alternatives for the everydrop water filter 3 replacement are widely available at lower prices. Here is an honest comparison:

Feature	EveryDrop EDR3RXD1 (OEM)	Generic Alternative
NSF certified contaminants	24	Typically 2-7
Guaranteed fit	Yes	Varies by brand
Whirlpool/KitchenAid warranty	Protected	May void warranty
Price	$45-$55	$15-$30
Lead + cyst reduction	Yes — NSF 53 certified	Not always included

A budget-friendly NSF-certified generic handles basic chlorine and taste. But for households with children, elderly family members, or anyone with health concerns. The genuine EveryDrop EDR3RXD1 is the right call. It is the only option with full 24-contaminant NSF certification and zero warranty risk.

>> Shop the Genuine EveryDrop EDR3RXD1 at UnifiedFilter.com >>

Frequently Asked Questions

Is the EDR3RXD1 the same as Filter 3?

Yes , Filter 3 is the label name and EDR3RXD1 is the part number, same product.

What does the EDR3RXD1 replace?

It is the direct replacement for the older W10193691 , same fit, improved filtration.

Where is the Filter 3 located on my refrigerator?

In the base grille at the very bottom front of the fridge, usually on the left side.

Is the EDR3RXD1 compatible with KitchenAid refrigerators?

Yes , It is the standard filter for most KitchenAid side-by-side refrigerators.

What is the difference between EDR3RXD1 and EDR2RXD1?

EDR3RXD1 mounts in the base grille for side-by-side fridges; EDR2RXD1 mounts in the interior upper housing for French door models , not interchangeable.

What is the difference between EDR3RXD1 and EDR3RXD1B?

The B suffix is a minor revision. Both fit the same fridges and perform identically.

How do I reset the filter light after replacing the EDR3RXD1?

Hold the filter reset button for 3 seconds until the indicator turns green or blue.

How long does the EDR3RXD1 last?

6 months or 200 gallons,  whichever comes first.

Do I need to flush the new filter after installing it?

Yes, Run 2-3 gallons through the dispenser and discard before drinking.

Can I use a generic filter instead of the genuine EDR3RXD1?

Yes if NSF-certified and compatible, but it may void your Whirlpool or KitchenAid warranty.

Ready to Order the EDR3RXD1?

The everydrop filter 3 is available at UnifiedFilter.com — genuine OEM, in stock, fast USA shipping. Single filters and 3-packs available.

>> Get the EveryDrop EDR3RXD1 at UnifiedFilter.com — Genuine OEM, Fast Shipping >>

Always verify compatibility with your specific fridge model before ordering. Check the label on your current installed filter or your owner’s manual.
